Indoor Unit SiBE121021_C
66 Printed Circuit Board Connector Wiring Diagram
PCB Detail [A1P]: Control PCB
X25A
X18A
X61A
X36A
X40A
X17A
X15A
HAP
X5AX35AX24A
X60A
X19A
X11A
X33A
X10A
X27A
X20A
2P095006-8
