eleTrICal daTa
www.DaikinApplied.com 35 IM 1137-4 • TEMPLIFIER
®
MODEL TGZ
Table 23: Multi-Point with External Overloads
NOTE: “Maximum Fuse Sizes” are selected at approximately 225% of the largest compressor RLA plus 100% of other compressor RLA
values.
Model Voltage Cir #1 Field Wire Max. Cir #2 Field Wire Max.
Size Size Hz MCA Qty Wire GA FS MCA Qty Wire GA FS
040B
208 60 69 3 4 AWG 100 69 3 4 AWG 100
230 60 63 3 6 AWG 90 63 3 6 AWG 90
380 60 38 3 8 AWG 50 38 3 8 AWG 50
460/400 60/50 32 3 10 AWG 45 32 3 10 AWG 45
575 60 25 3 10 AWG 35 25 3 10 AWG 35
050B
208 60 95 3 3 AWG 125 95 3 3 AWG 125
230 60 86 3 3 AWG 125 86 3 3 AWG 125
380 60 52 3 6 AWG 70 52 3 6 AWG 70
460/400 60/50 43 3 8 AWG 60 43 3 8 AWG 60
575 60 34 3 10 AWG 45 34 3 10 AWG 50
060B
208 60 117 3 1 AWG 150 117 3 1 AWG 150
230 60 110 3 2 AWG 150 110 3 2 AWG 150
380 60 67 3 4 AWG 90 67 3 4 AWG 90
460/400 60/50 55 3 6 AWG 80 55 3 6 AWG 80
575 60 44 3 8 AWG 60 44 3 8 AWG 60
080B
208 60 131 3 1/0 AWG 175 131 3 1/0 AWG 175
230 60 119 3 1 AWG 150 119 3 1 AWG 150
380 60 71 3 4 AWG 100 71 3 4 AWG 100
460/400 60/50 59 3 6 AWG 80 59 3 6 AWG 80
575 60 48 3 8 AWG 60 48 3 8 AWG 60
100B
208 60 156 3 2/0 AWG 225 156 3 2/0 AWG 225
230 60 140 3 1/0 AWG 200 140 3 1/0 AWG 200
380 60 85 3 4 AWG 110 85 3 4 AWG 110
460/400 60/50 70 3 4 AWG 100 70 3 4 AWG 100
575 60 57 3 6 AWG 80 57 3 6 AWG 80
110B
208 60 156 3 2/0 AWG 225 200 3 3/0 AWG 250
230 60 140 3 1/0 AWG 200 180 3 3/0 AWG 250
380 60 85 3 4 AWG 110 108 3 2 AWG 150
460/400 60/50 70 3 4 AWG 100 90 3 3 AWG 125
575 60 57 3 6 AWG 80 72 3 4 AWG 100
120B
208 60 200 3 3/0 AWG 250 200 3 3/0 AWG 250
230 60 180 3 3/0 AWG 250 180 3 3/0 AWG 250
380 60 108 3 2 AWG 150 108 3 2 AWG 150
460/400 60/50 90 3 3 AWG 125 90 3 3 AWG 125
575 60 72 3 4 AWG 100 72 3 4 AWG 100
150B
208 60 225 3 4/0 AWG 250 225 3 4/0 AWG 250
230 60 203 3 4/0 AWG 250 203 3 4/0 AWG 250
380 60 122 3 1 AWG 150 122 3 1 AWG 150
460/400 60/50 101 3 2 AWG 125 101 3 2 AWG 125
575 60 82 3 4 AWG 100 82 3 4 AWG 100
170B
208 60 225 3 4/0 AWG 250 289 3 350 MCM 350
230 60 203 3 4/0 AWG 250 260 3 300 MCM 300
380 60 122 3 1 AWG 150 156 3 2/0 AWG 200
460/400 60/50 101 3 2 AWG 125 130 3 1 AWG 150
575 60 82 3 4 AWG 100 104 3 2 AWG 125
190B
208 60 289 3 350 MCM 350 289 3 350 MCM 350
230 60 260 3 300 MCM 300 260 3 300 MCM 300
380 60 156 3 2/0 AWG 200 156 3 2/0 AWG 200
460/400 60/50 130 3 1 AWG 150 130 3 1 AWG 150
575 60 104 3 2 AWG 125 104 3 2 AWG 125
