eleTrICal daTa
Table 22: Single Point without External Overloads
NOTE: 1. Unit wire sizing amps are equal to 125% of the largest compressor-motor RLA plus 100% of the other compressor RLA’s.
2. Single point power supply requires a single fused disconnect to supply electrical power to the unit.
3. External compressor overload option is only available for units with 140°F maximum leaving condenser water temperature.
4. Wire Sizes shown above are for standard ambient temperature and short runs of wire.
Model Voltage MCA Field Wire Max. Power Block [2] Disconnect Switch [2]
Size Size Hz Qty Wire GA FS Size Lug Range Size Lug Range
040B
208 60 150 3 1/0 AWG 175 380A (1) 500 - #4 250A (1) 350 - #6
230 60 150 3 1/0 AWG 175 380A (1) 500 - #4 250A (1) 350 - #6
380 60 91 3 3 AWG 110 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
460/400 60/50 77 3 4 AWG 90 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
575 60 49 3 8 AWG 60 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
050B
208 60 205 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
230 60 205 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
380 60 109 3 2 AWG 125 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
460/400 60/50 93 3 3 AWG 110 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
575 60 80 3 4 AWG 90 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
060B
208 60 224 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
230 60 224 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
380 60 137 3 1/0 AWG 150 175A (1) 2/0 - #14 250A (1) 350 - #6
460/400 60/50 109 3 2 AWG 125 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
575 60 91 3 3 AWG 110 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
080B
208 60 311 3 400 MCM 350 380A (1) 500 - #4 400A (2) 500 - 3/0
230 60 311 3 400 MCM 350 380A (1) 500 - #4 400A (2) 500 - 3/0
380 60 161 3 2/0 AWG 175 175A (1) 2/0 - #14 250A (1) 350 - #6
460/400 60/50 128 3 1 AWG 150 175A (1) 2/0 - #14 250A (1) 350 - #6
575 60 104 3 2 AWG 125 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
100B
208 60 311 3 400 MCM 350 380A (1) 500 - #4 400A (2) 500 - 3/0
230 60 311 3 400 MCM 350 380A (1) 500 - #4 400A (2) 500 - 3/0
380 60 191 3 3/0 AWG 225 380A (1) 500 - #4 250A (1) 350 - #6
460/400 60/50 150 3 1/0 AWG 175 175A (1) 2/0 - #14 250A (1) 350 - #6
575 60 120 3 1 AWG 125 175A (1) 2/0 - #14 250A (1) 350 - #6
110B
208 60 357 6 4/0 AWG 450 380A (1) 500 - #4 400A (2) 500 - 3/0
230 60 357 6 4/0 AWG 450 380A (1) 500 - #4 400A (2) 500 - 3/0
380 60 210 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
460/400 60/50 173 3 2/0 AWG 200 380A (1) 500 - #4 250A (1) 350 - #6
575 60 139 3 1/0 AWG 175 175A (1) 2/0 - #14 250A (1) 350 - #6
120B
208 60 398 6 250 MCM 450 760A (2) 500 - #4 600A (2) 500 - 3/0
230 60 398 6 250 MCM 450 760A (2) 500 - #4 600A (2) 500 - 3/0
380 60 227 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
460/400 60/50 194 3 3/0 AWG 225 380A (1) 500 - #4 250A (1) 350 - #6
575 60 156 3 2/0 AWG 175 175A (1) 2/0 - #14 250A (1) 350 - #6
150B
208 60 457 6 4/0 AWG 500 760A (2) 500 - #4 600A (2) 500 - 3/0
230 60 457 6 4/0 AWG 500 760A (2) 500 - #4 600A (2) 500 - 3/0
380 60 281 3 300 MCM 300 380A (1) 500 - #4 400A (2) 500 - 3/0
460/400 60/50 221 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
575 60 177 3 3/0 AWG 200 380A (1) 500 - #4 250A (1) 350 - #6
170B
208 60 524 6 300 MCM 600 760A (2) 500 - #4 600A (2) 500 - 3/0
230 60 524 6 300 MCM 600 760A (2) 500 - #4 600A (2) 500 - 3/0
380 60 308 3 350 MCM 350 380A (1) 500 - #4 400A (2) 500 - 3/0
460/400 60/50 254 3 250 MCM 300 380A (1) 500 - #4 400A (2) 500 - 3/0
575 60 204 3 4/0 AWG 225 380A (1) 500 - #4 250A (1) 350 - #6
190B
208 60 585 6 350 MCM 600 760A (2) 500 - #4 800A (3) 500 - 3/0
230 60 585 6 350 MCM 600 760A (2) 500 - #4 800A (3) 500 - 3/0
380 60 333 3 400 MCM 350 380A (1) 500 - #4 400A (2) 500 - 3/0
460/400 60/50 285 3 300 MCM 300 380A (1) 500 - #4 400A (2) 500 - 3/0
575 60 229 3 4/0 AWG 250 380A (1) 500 - #4 400A (2) 500 - 3/0
