MODEL TGZ
Table 21: Single Point with External Overloads
NOTE: 1. Unit wire sizing amps are equal to 125% of the largest compressor-motor RLA plus 100% of the other compressor RLA’s.
2. Multiple point power supply requires a separate fused disconnect for each circuit to supply electrical power to the unit.
3. External compressor overload option is only available for units with 140°F maximum leaving condenser water temperature.
4. Wire sizes shown above are for standard ambient temperature and short runs of wire.
Model Voltage MCA Field Wire Max. Power Block [2] Disconnect Switch [2]
Size Size Hz Qty Wire GA FS Size Lug Range Size Lug Range
040B
208 60 131 3 1/0 AWG 150 175A (1) 2/0 - #14 250A (1) 350 - #6
230 60 119 3 1 AWG 125 175A (1) 2/0 - #14 250A (1) 350 - #6
380 60 72 3 4 AWG 80 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
460/400 60/50 60 3 6 AWG 70 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
575 60 48 3 8 AWG 50 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
050B
208 60 179 3 3/0 AWG 200 380A (1) 500 - #4 250A (1) 350 - #6
230 60 164 3 2/0 AWG 200 175A (1) 2/0 - #14 250A (1) 350 - #6
380 60 99 3 3 AWG 110 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
460/400 60/50 82 3 4 AWG 100 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
575 60 65 3 6 AWG 80 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
060B
208 60 221 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
230 60 208 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
380 60 126 3 1 AWG 150 175A (1) 2/0 - #14 250A (1) 350 - #6
460/400 60/50 104 3 2 AWG 125 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
575 60 84 3 4 AWG 100 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
080B
208 60 247 3 250 MCM 300 380A (1) 500 - #4 400A (2) 500 - 3/0
230 60 225 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
380 60 135 3 1/0 AWG 150 175A (1) 2/0 - #14 250A (1) 350 - #6
460/400 60/50 113 3 2 AWG 125 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
575 60 91 3 3 AWG 110 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
100B
208 60 295 3 350 MCM 350 380A (1) 500 - #4 400A (2) 500 - 3/0
230 60 266 3 300 MCM 300 380A (1) 500 - #4 400A (2) 500 - 3/0
380 60 160 3 2/0 AWG 175 175A (1) 2/0 - #14 250A (1) 350 - #6
460/400 60/50 133 3 1/0 AWG 150 175A (1) 2/0 - #14 250A (1) 350 - #6
575 60 108 3 2 AWG 125 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
110B
208 60 339 6 4/0 AWG 400 380A (1) 500 - #4 400A (2) 500 - 3/0
230 60 305 3 350 MCM 350 380A (1) 500 - #4 400A (2) 500 - 3/0
380 60 184 3 3/0 AWG 225 380A (1) 500 - #4 250A (1) 350 - #6
460/400 60/50 153 3 2/0 AWG 175 175A (1) 2/0 - #14 250A (1) 350 - #6
575 60 123 3 1 AWG 150 175A (1) 2/0 - #14 250A (1) 350 - #6
120B
208 60 378 6 250 MCM 450 380A (1) 500 - #4 600A (2) 500 - 3/0
230 60 340 6 4/0 AWG 400 380A (1) 500 - #4 400A (2) 500 - 3/0
380 60 204 3 4/0 AWG 250 380A (1) 500 - #4 250A (1) 350 - #6
460/400 60/50 170 3 2/0 AWG 200 380A (1) 500 - #4 250A (1) 350 - #6
575 60 136 3 1/0 AWG 150 175A (1) 2/0 - #14 250A (1) 350 - #6
150B
208 60 433 6 4/0 AWG 500 760A (2) 500 - #4 600A (2) 500 - 3/0
230 60 390 6 250 MCM 450 760A (2) 500 - #4 600A (2) 500 - 3/0
380 60 235 3 250 MCM 250 380A (1) 500 - #4 400A (2) 500 - 3/0
460/400 60/50 195 3 3/0 AWG 225 380A (1) 500 - #4 250A (1) 350 - #6
575 60 158 3 2/0 AWG 175 175A (1) 2/0 - #14 250A (1) 350 - #6
170B
208 60 497 6 250 MCM 500 760A (2) 500 - #4 600A (2) 500 - 3/0
230 60 448 6 4/0 AWG 500 760A (2) 500 - #4 600A (2) 500 - 3/0
380 60 269 3 300 MCM 300 380A (1) 500 - #4 400A (2) 500 - 3/0
460/400 60/50 224 3 4/0 AWG 250 380A (1) 500 - #4 400A (2) 500 - 3/0
575 60 180 3 3/0 AWG 200 380A (1) 500 - #4 250A (1) 350 - #6
190B
208 60 555 6 300 MCM 600 760A (2) 500 - #4 800A (3) 500 - 3/0
230 60 500 6 250 MCM 500 760A (2) 500 - #4 600A (2) 500 - 3/0
380 60 300 3 350 MCM 300 380A (1) 500 - #4 400A (2) 500 - 3/0
460/400 60/50 250 3 250 MCM 300 380A (1) 500 - #4 400A (2) 500 - 3/0
575 60 200 3 4/0 AWG 225 380A (1) 500 - #4 250A (1) 350 - #6
