IM 1137-4 • TEMPLIFIER
®
MODEL TGZ 32 www.DaikinApplied.com
eleTrICal daTa
Table 20: RLA-LRA
NOTE: 1. External overloads only available on Templier units with 140°F maximum condenser leaving water temperature.
2. Unit wire sizing amps are equal to 125% of the largest compressor-motor RLA plus 100% of RLA of all other loads in the circuit
including control transformer.
3. Single point power supply requires a single fused disconnect to supply electrical power to the unit.
4. Compressor RLA values are for wire sizing purposes only and do not reect normal operating current draw.
Model Voltage Compressors RLA with Overload Compressors RLA without Overload Compressors LRA
Size Size Hz #1 #3 #5 #2 #4 #6 #1 #3 #5 #2 #4 #6 #1 #3 #5 #2 #4 #6
040B
208 60 30.8 30.8 -- 30.8 30.8 -- 35.3 35.3 -- 35.3 35.3 -- 239 239 -- 239 239 --
230 60 28.0 28.0 -- 28.0 28.0 -- 35.3 35.3 -- 35.3 35.3 -- 239 239 -- 239 239 --
380 60 16.8 16.8 -- 16.8 16.8 -- 21.2 21.2 -- 21.2 21.2 -- 145 145 -- 145 145 --
460/400 60/50 14.0 14.0 -- 14.0 14.0 -- 17.9 17.9 -- 17.9 17.9 -- 125 / 118 125 / 118 -- 125 / 118 125 / 118 --
575 60 11.2 11.2 -- 11.2 11.2 -- 11.5 11.5 -- 11.5 11.5 -- 80 80 -- 80 80 --
050B
208 60 42.0 42.0 -- 42.0 42.0 -- 48.1 48.1 -- 48.1 48.1 -- 300 300 -- 300 300 --
230 60 38.4 38.4 -- 38.4 38.4 -- 48.1 48.1 -- 48.1 48.1 -- 300 300 -- 300 300 --
380 60 23.2 23.2 -- 23.2 23.2 -- 25.6 25.6 -- 25.6 25.6 -- 139 139 -- 139 139 --
460/400 60/50 19.2 19.2 -- 19.2 19.2 -- 21.8 21.8 -- 21.8 21.8 -- 150 / 140 150 / 140 -- 150 / 140 150 / 140 --
575 60 15.2 15.2 -- 15.2 15.2 -- 18.6 18.6 -- 18.6 18.6 -- 109 109 -- 109 109 --
060B
208 60 52.0 52.0 -- 52.0 52.0 -- 52.6 52.6 -- 52.6 52.6 -- 340 340 -- 340 340 --
230 60 48.8 48.8 -- 48.8 48.8 -- 52.6 52.6 -- 52.6 52.6 -- 340 340 -- 340 340 --
380 60 29.6 29.6 -- 29.6 29.6 -- 32.1 32.1 -- 32.1 32.1 -- 196 196 -- 196 196 --
460/400 60/50 24.4 24.4 -- 24.4 24.4 -- 25.6 25.6 -- 25.6 25.6 -- 173 173 -- 173 173 --
575 60 19.6 19.6 -- 19.6 19.6 -- 21.2 21.2 -- 21.2 21.2 -- 132 132 -- 132 132 --
080B
208 60 58.0 58.0 -- 58.0 58.0 -- 73.1 73.1 -- 73.1 73.1 -- 505 505 -- 505 505 --
230 60 52.8 52.8 -- 52.8 52.8 -- 73.1 73.1 -- 73.1 73.1 -- 505 505 -- 505 505 --
380 60 31.6 31.6 -- 31.6 31.6 -- 37.8 37.8 -- 37.8 37.8 -- 280 280 -- 280 280 --
460/400 60/50 26.4 26.4 -- 26.4 26.4 -- 30.1 30.1 -- 30.1 30.1 -- 225 225 -- 225 225 --
575 60 21.2 21.2 -- 21.2 21.2 -- 24.4 24.4 -- 24.4 24.4 -- 180 180 -- 180 180 --
100B
208 60 69.2 69.2 -- 69.2 69.2 -- 73.1 73.1 -- 73.1 73.1 -- 500 500 -- 500 500 --
230 60 62.4 62.4 -- 62.4 62.4 -- 73.1 73.1 -- 73.1 73.1 -- 500 500 -- 500 500 --
380 60 37.6 37.6 -- 37.6 37.6 -- 44.9 44.9 -- 44.9 44.9 -- 305 305 -- 305 305 --
460/400 60/50 31.2 31.2 -- 31.2 31.2 -- 35.3 35.3 -- 35.3 35.3 -- 250 250 -- 250 250 --
575 60 25.2 25.2 -- 25.2 25.2 -- 28.2 28.2 -- 28.2 28.2 -- 198 198 -- 198 198 --
110B
208 60 69.2 69.2 -- 88.8 88.8 -- 73.1 73.1 -- 93.6 93.6 -- 500 500 -- 599 599 --
230 60 62.4 62.4 -- 80.0 80.0 -- 73.1 73.1 -- 93.6 93.6 -- 500 500 -- 599 599 --
380 60 37.6 37.6 -- 48.0 48.0 -- 44.9 44.9 -- 53.2 53.2 -- 305 305 -- 358 358 --
460/400 60/50 31.2 31.2 -- 40.0 40.0 -- 35.3 35.3 -- 45.5 45.5 -- 250 250 -- 310 310 --
575 60 25.2 25.2 -- 32.0 32.0 -- 28.2 28.2 -- 36.5 36.5 -- 198 198 -- 239 239 --
120B
208 60 88.8 88.8 -- 88.8 88.8 -- 93.6 93.6 -- 93.6 93.6 -- 599 599 -- 599 599 --
230 60 80.0 80.0 -- 80.0 80.0 -- 93.6 93.6 -- 93.6 93.6 -- 599 599 -- 599 599 --
380 60 48.0 48.0 -- 48.0 48.0 -- 53.2 53.2 -- 53.2 53.2 -- 358 358 -- 358 358 --
460/400 60/50 40.0 40.0 -- 40.0 40.0 -- 45.5 45.5 -- 45.5 45.5 -- 310 310 -- 310 310 --
575 60 32.0 32.0 -- 32.0 32.0 -- 36.5 36.5 -- 36.5 36.5 -- 239 239 -- 239 239 --
150B
208 60 69.2 69.2 69.2 69.2 69.2 69.2 73.1 73.1 73.1 73.1 73.1 73.1 500 500 500 500 500 500
230 60 62.4 62.4 62.4 62.4 62.4 62.4 73.1 73.1 73.1 73.1 73.1 73.1 500 500 500 500 500 500
380 60 37.6 37.6 37.6 37.6 37.6 37.6 44.9 44.9 44.9 44.9 44.9 44.9 305 305 305 305 305 305
460/400 60/50 31.2 31.2 31.2 31.2 31.2 31.2 35.3 35.3 35.3 35.3 35.3 35.3 250 250 250 250 250 250
575 60 25.2 25.2 25.2 25.2 25.2 25.2 28.2 28.2 28.2 28.2 28.2 28.2 198 198 198 198 198 198
170B
208 60 69.2 69.2 69.2 88.8 88.8 88.8 73.1 73.1 73.1 93.6 93.6 93.6 500 500 500 599 599 599
230 60 62.4 62.4 62.4 80.0 80.0 80.0 73.1 73.1 73.1 93.6 93.6 93.6 500 500 500 599 599 599
380 60 37.6 37.6 37.6 48.0 48.0 48.0 44.9 44.9 44.9 53.2 53.2 53.2 305 305 305 358 358 358
460/400 60/50 31.2 31.2 31.2 40.0 40.0 40.0 35.3 35.3 35.3 45.5 45.5 45.5 250 250 250 310 310 310
575 60 25.2 25.2 25.2 32.0 32.0 32.0 28.2 28.2 28.2 36.5 36.5 36.5 198 198 198 239 239 239
190B
208 60 88.8 88.8 88.8 88.8 88.8 88.8 93.6 93.6 93.6 93.6 93.6 93.6 599 599 599 599 599 599
230 60 80.0 80.0 80.0 80.0 80.0 80.0 93.6 93.6 93.6 93.6 93.6 93.6 599 599 599 599 599 599
380 60 48.0 48.0 48.0 48.0 48.0 48.0 53.2 53.2 53.2 53.2 53.2 53.2 358 358 358 358 358 358
460/400 60/50 40.0 40.0 40.0 40.0 40.0 40.0 45.5 45.5 45.5 45.5 45.5 45.5 310 310 310 310 310 310
575 60 32.0 32.0 32.0 32.0 32.0 32.0 36.5 36.5 36.5 36.5 36.5 36.5 239 239 239 239 239 239
