eleTrICal daTa
www.DaikinApplied.com 37 IM 1137-4 • TEMPLIFIER
®
MODEL TGZ
Table 25: Multi-Point without External Overloads
NOTE: 1. On HSCCR Unit = 250A {(1) 350 - #6}
2. Power Block and Disconnect Switch sizes are the minimum. Larger sizes may be used, however the lug range must be the same.
3. “Size” is the maximum amperage rating for the terminals or the main electrical device. “Connection” is the range of wire sizes that
the terminals on the electrical device will accept.
Model Voltage Cir #1 Field Wire Max. Cir #2 Field Wire Max.
Size Size Hz MCA Qty Wire GA FS MCA Qty Wire GA FS
040B
208 60 79 3 4 AWG 110 79 3 4 AWG 110
230 60 79 3 4 AWG 110 79 3 4 AWG 110
380 60 48 3 8 AWG 60 48 3 8 AWG 60
460/400 60/50 40 3 8 AWG 50 40 3 8 AWG 50
575 60 26 3 10 AWG 35 26 3 10 AWG 35
050B
208 60 108 3 2 AWG 150 108 3 2 AWG 150
230 60 108 3 2 AWG 150 108 3 2 AWG 150
380 60 58 3 6 AWG 80 58 3 6 AWG 80
460/400 60/50 49 3 8 AWG 70 49 3 8 AWG 70
575 60 42 3 8 AWG 60 42 3 8 AWG 60
060B
208 60 118 3 1 AWG 150 118 3 1 AWG 150
230 60 118 3 1 AWG 150 118 3 1 AWG 150
380 60 72 3 4 AWG 100 72 3 4 AWG 100
460/400 60/50 58 3 6 AWG 80 58 3 6 AWG 80
575 60 48 3 8 AWG 60 48 3 8 AWG 60
080B
208 60 164 3 2/0 AWG 225 164 3 2/0 AWG 225
230 60 164 3 2/0 AWG 225 164 3 2/0 AWG 225
380 60 85 3 4 AWG 110 85 3 4 AWG 110
460/400 60/50 68 3 4 AWG 90 68 3 4 AWG 90
575 60 55 3 6 AWG 70 55 3 6 AWG 80
100B
208 60 164 3 2/0 AWG 225 164 3 2/0 AWG 225
230 60 164 3 2/0 AWG 225 164 3 2/0 AWG 225
380 60 101 3 2 AWG 125 101 3 2 AWG 125
460/400 60/50 79 3 4 AWG 110 79 3 4 AWG 110
575 60 63 3 6 AWG 90 63 3 6 AWG 90
110B
208 60 164 3 2/0 AWG 225 211 3 4/0 AWG 300
230 60 164 3 2/0 AWG 225 211 3 4/0 AWG 300
380 60 101 3 2 AWG 125 120 3 1 AWG 150
460/400 60/50 79 3 4 AWG 110 102 3 2 AWG 125
575 60 63 3 6 AWG 90 82 3 4 AWG 110
120B
208 60 211 3 4/0 AWG 300 211 3 4/0 AWG 300
230 60 211 3 4/0 AWG 300 211 3 4/0 AWG 300
380 60 120 3 1 AWG 150 120 3 1 AWG 150
460/400 60/50 102 3 2 AWG 125 102 3 2 AWG 125
575 60 82 3 4 AWG 110 82 3 4 AWG 110
150B
208 60 238 3 250 MCM 300 238 3 250 MCM 300
230 60 238 3 250 MCM 300 238 3 250 MCM 300
380 60 146 3 1/0 AWG 175 146 3 1/0 AWG 175
460/400 60/50 115 3 2 AWG 150 115 3 2 AWG 150
575 60 92 3 3 AWG 110 92 3 3 AWG 110
170B
208 60 238 3 250 MCM 300 304 3 350 MCM 350
230 60 238 3 250 MCM 300 304 3 350 MCM 350
380 60 146 3 1/0 AWG 175 173 3 2/0 AWG 225
460/400 60/50 115 3 2 AWG 150 148 3 1/0 AWG 175
575 60 92 3 3 AWG 110 119 3 1 AWG 150
190B
208 60 304 3 350 MCM 350 304 3 350 MCM 350
230 60 304 3 350 MCM 350 304 3 350 MCM 350
380 60 173 3 2/0 AWG 225 173 3 2/0 AWG 225
460/400 60/50 148 3 1/0 AWG 175 148 3 1/0 AWG 175
575 60 119 3 1 AWG 150 119 3 1 AWG 150
