IM 1137-4 • TEMPLIFIER
®
MODEL TGZ 38 www.DaikinApplied.com
eleTrICal daTa
Table 26: Multi-Point without External Overloads
NOTE: 1. On HSCCR Unit = 250A {(1) 350 - #6}
2. Power Block and Disconnect Switch sizes are the minimum. Larger sizes may be used, however the lug range must be the same.
3. “Size” is the maximum amperage rating for the terminals or the main electrical device. “Connection” is the range of wire sizes that
the terminals on the electrical device will accept.
Model Voltage Cir #1 Power Block [2] Cir #1 Disconnect Sw [2] Cir #2 Power Block [2] Cir #2 Disconnect Sw [2]
Size Size Hz Size Lug Range Size Lug Range Size Lug Range Size Lug Range
040B
208 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
230 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
380 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
460/400 60/50 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
575 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
050B
208 60 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 125A (1) 3/0 - #3
230 60 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 125A (1) 3/0 - #3
380 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
460/400 60/50 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
575 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
060B
208 60 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 125A (1) 3/0 - #3
230 60 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 125A (1) 3/0 - #3
380 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
460/400 60/50 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
575 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
080B
208 60 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
230 60 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
380 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
460/400 60/50 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
575 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
100B
208 60 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
230 60 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
380 60 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 125A (1) 3/0 - #3
460/400 60/50 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
575 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
110B
208 60 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
230 60 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
380 60 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 125A (1) 3/0 - #3
460/400 60/50 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 125A (1) 3/0 - #3
575 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
120B
208 60 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
230 60 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
380 60 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 125A (1) 3/0 - #3
460/400 60/50 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 125A (1) 3/0 - #3
575 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
150B
208 60 380A (1) 500 - #4 400A (2) 500 - 3/0 380A (1) 500 - #4 400A (2) 500 - 3/0
230 60 380A (1) 500 - #4 400A (2) 500 - 3/0 380A (1) 500 - #4 400A (2) 500 - 3/0
380 60 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
460/400 60/50 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 125A (1) 3/0 - #3
575 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 100A (1) 1/0 - #10
170B
208 60 380A (1) 500 - #4 400A (2) 500 - 3/0 380A (1) 500 - #4 400A (2) 500 - 3/0
230 60 380A (1) 500 - #4 400A (2) 500 - 3/0 380A (1) 500 - #4 400A (2) 500 - 3/0
380 60 175A (1) 2/0 - #14 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
460/400 60/50 175A (1) 2/0 - #14 125A (1) 3/0 - #3 175A (1) 2/0 - #14 250A (1) 350 - #6
575 60 175A (1) 2/0 - #14 100A (1) 1/0 - #10 175A (1) 2/0 - #14 250A (1) 350 - #6
190B
208 60 380A (1) 500 - #4 400A (2) 500 - 3/0 380A (1) 500 - #4 400A (2) 500 - 3/0
230 60 380A (1) 500 - #4 400A (2) 500 - 3/0 380A (1) 500 - #4 400A (2) 500 - 3/0
380 60 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
460/400 60/50 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
575 60 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
