FRAME & BUMPERS
TABLE OF CONTENTS
page page
BUMPERS
SPECIFICATIONS - TORQUE ...............1
FRONT BUMPER - STEPS
REMOVAL .............................2
INSTALLATION ..........................2
FRONT FASCIA
REMOVAL .............................2
INSTALLATION ..........................2
REAR BUMPER - STEP
REMOVAL .............................2
INSTALLATION ..........................3
REAR FASCIA
REMOVAL .............................3
INSTALLATION ..........................3
FRAME
SPECIFICATIONS
SPECIFICATIONS - FRAME DIMENSIONS . . . 3
SPECIFICATIONS - TORQUE .............8
ENGINE CRADLE CROSSMEMBER
REMOVAL .............................8
INSTALLATION .........................10
REAR CROSSMEMBER - TRANSMISSION
REMOVAL .............................11
INSTALLATION .........................11
TRAILER HITCH
REMOVAL .............................11
INSTALLATION .........................12
BUMPERS
SPECIFICATIONS - TORQUE
TORQUE SPECIFICATIONS
DESCRIPTION N·m Ft. Lbs. In. Lbs.
FRONT BUMPER - STEPS BOLTS 20 15 —
FRONT FASCIA SCREWS 23 17 —
REAR BUMPER STEP FRAME BOLTS/
NUTS
38 17 —
REAR BUMPER STEP SUPPORT BOLTS 90 66 —
REAR FASCIA BOLTS 23 17 —
VA FRAME & BUMPERS 13 - 1
