DESCRIPTION N·m Ft. Lbs. In. Lbs.
Bottom Spring Clamp
Plate To Front Axle
M10 Bolt
65 48 —
Sway Bar Clamp To The
Front Axle
30 22 —
Hexagon Socket Bolt For
Clamping Nut To Adjust
Wheel Bearing Play
12 9 106
Lower Control Arm To
Front Axle Beam
150 110 —
Stop Plate For Lower
Control Arm
60 44 —
Outer Tie Rod End Nut 130 96 —
Outer Tie Rod End Nut
Jam Nut
50 37 —
SPECIAL TOOLS
FRONT SUSPENSION
SPECIAL TOOL CROSS REFERENCE CHART
MB
TOOL #
MILLER
TOOL #
DESCRIPTION
N/A 9288 LEAF SPRING WEDGE
BLOCK
N/A 9294 LOWER BALL JOINT RE-
MOVE/INSTALLER
N/A 9302 BUSHING REMOVER /IN-
STALLER
N/A C-3894-A PULLER TIE ROD
730 589
02 33 00
9282 BALL JOINT SEPARA-
TOR
N/A C-4212F BALL JOINT PRESS
Puller Tie Rod C-3894-A
BALL JOINT PRESS - C-4212F
LOWER BALL JOINT REMOVE / INSTALL - 9294
2 - 2 FRONT VA
