Daintree GE Current WFA100-SN - Installation Tests; Test Suite

Installation GuideDaintree
®
Networked Wireless Fixture Adapter (WFA100-SN)
9
5
Alllightingdevices,includingwirelessadaptersmustbetested
for proper operation.
Aftermounting,wiringlowvoltage,wiringlinevoltage,powering
upandresettingtheunit,performtherecommendedInstallation
Test. The Installation Test mode automatically times out after
5 minutes of no activity.
WhiletheWFA100-SNisinInstallationTestmode,thelowvoltage
devices connected to the WFA100-SN directly control the lights
wiredtothesameWFA100-SN.AfteryouexitInstallationTest
mode,thelightsturnOnandareNOTcontrolledbythedevices
connected to the WFA100-SN. After commissioning the
DaintreeNetworked,lightingcontrolisdeterminedby
congurationsettingsintheDaintreeControlsSoftware.
TestSuite1:
Dimming or On/Off Ballasts Only
1.PressandimmediatelyreleasetheResetbutton.The
 redErrorLEDashesonce,thenpausesandrepeats.
2.CheckthattheconnectedlightscycleOnandOff,orcycle
  frommaximumtominimumbrightnessthenturnOff, 
then repeat the cycle.
3.PressandimmediatelyreleasetheResetbuttontoexit
testing.
4.PressandholdtheResetbuttonontheWFA100-SNfor3 
  secondstoresetit.Releasethebuttonwhenthegreen
  JoinedLEDandtheredErrorLEDsbeginashing.
TestSuite2:
Dimming or On/Off Ballasts Only
1.PressandimmediatelyreleasetheResetbutton.Thered 
  ErrorLEDashesonce,thenpausesandrepeats.
2. CheckthattheconnectedlightscycleOnandOff,orcycle
  frommaximumtominimumbrightnessthenturnOff,
then repeat the cycle.
3.PressandimmediatelyreleasetheResetbuttonagain.
  TheredErrorLEDashestwice,thenpausesandrepeats.
4. Trigger the occupancy sensor. The light connected to the
  ballastturnsOn.Whenthesensortimesoutthelight
turns Off.
5.PressandimmediatelyreleasetheResetbuttontoexit
testing.
6.PressandholdtheResetbuttonontheWFA100-SNfor
  3secondstoresetit.Releasethebuttonwhenthe
  greenJoinedLEDandtheredErrorLEDsbegin
  ashing.
TestSuite3:
Dimming or On/Off Ballast + Photosensor
1.PressandimmediatelyreleasetheResetbutton.The
  redErrorLEDashesonce,thenpausesandrepeats.
2. CheckthattheconnectedlightscycleOnandOff,orcycle
  frommaximumtominimumbrightnessthenturnOff, 
then repeat the cycle.
3.PressandimmediatelyreleasetheResetbuttonagain. 
  TheredErrorLEDashesthreetimes,thenpausesand 
repeats.
4.ThelightconnectedtotheballastturnsOn.
5.Increasetheamountoflightatthephotosensorbyshining
  abrightlightatit.Thelightdimstominimum
  brightness,thenrampsuptofullbrightnessafter2
  seconds.Forswitchedlights,theOn/Offcycletakes
  3seconds.Maintainingthebrightlightatthephotosensor
  causesthedimmingorOn/Offcycletorepeatperiodically.
6.PressandimmediatelyreleasetheResetbuttontoexit 
testing.
7. PressandholdtheResetbuttonontheWFA100-SNfor
  3secondstoresetit.Releasethebuttonwhenthe
  greenJoinedLEDandtheredErrorLEDsbegin
  ashing.
TestSuite4:
Dimming or On/Off Ballast + Occupancy Sensor + Photosensor
1.PressandimmediatelyreleasetheResetbutton.The
  redErrorLEDashesonce,thenpausesandrepeats.
2.CheckthattheconnectedlightscycleOnandOff,orcycle
  frommaximumtominimumbrightnessthenturnOff,then
repeat the cycle.
3.PressandimmediatelyreleasetheResetbutton.Thered 
  ErrorLEDashestwice,thenpausesandrepeats.
4. Trigger the occupancy sensor. The green Joined LED turns
  OnandthelightconnectedtotheballastturnsOn.When
the sensor times out the Joined LED and light turns Off.
5.PressandimmediatelyreleasetheResetbuttonagain. 
  TheredErrorLEDashesthreetimes,thenpausesand 
repeats.
6. ThelightconnectedtotheballastturnsOn.
7.Increasetheamountoflightatthephotosensorbyshining
  abrightlightatit.Thelightdimstominimumbrightness,
  thenrampsuptofullbrightnessafter2seconds.For 
  switchedlights,theOn/Offcycletakes3seconds.
  Maintainingthebrightlightatthephotosensorcausesthe
  dimmingorOn/Offcycletorepeatperiodically.
8. PressandimmediatelyreleasetheResetbuttontoexit 
testing.
9. PressandholdtheResetbuttonontheWFA100-SNfor3 
  secondstoresetit.Releasethebuttonwhenthegreen 
  JoinedLEDandtheredErrorLEDsbeginashing.
Installation Tests
