1.3 Specifications
Item Specifications
Print Method Line thermal print method
Printer SEIKO CAP G247A
Print Width 54 mm, 432 dots
Dot Density 8 dots/mm (Horizontal/Vertical)
Paper Feed Pitch 0.125 mm
Print Speed 100 mm/sec, Max 150 mm/sec
Number of print
columns
36 (Font A)
43 (Font B)
Character Size Font A: 12x22
Font B: 10x20
Bar Code Types EAN13, EAN8, UPC-A, UPC-E, Codebar,
Interleaved 2 of 5, Code 39, Code 93,
Code 128
Paper Thermal roll: Max W57mm, ø55mm
Paper Thickness 60-65 µm
Interface RS-232C Interface, max 115200 bps
Power Consumption 60W max
Adapter Input: AC 100-240V, 1.0A, 50/60Hz
Output: DC +24V, 2.5A
Weight
External Dimensions
Operating
Temperature
and Humidity
5 ÷ 40 ºC, 30 ÷ 85% RH
Storage Temperature -10 ÷ 60 ºC, 10 ÷ 90% RH
Reliability Print head life: 100 million pulses or 100
km print length.
Auto Cutter life: 1 million cuts.
