2.6 Power supply
INSTALLATION
MODE
Type of power supply to be installed according to media used:
• 2 x (3.6 v, 13 Ah) lithium power pack, BatLi 22
• Li-Ion = 3.7 V/1.2 Ah Li-Ion rechargeable back-up battery
• Mains power module = 200-240 VAC 50-60 Hz / 4.5 VDC 2.2 A internal mains power module
When using the transmission module card:
Accessories and power supplies to be used
The accessories and power supply(ies) needed to install the control panel-dialler depend on the type of transmission module and
media used. Before going out to the site, installers must make sure they have the additional accessories and power supply(ies)
listed in the “Appendix” chapter (besides any accessories that are supplied with control panel and transmission module).
Declaring unused media
To prevent faults from occurring due to line cuts or the absence of transmission media in user mode, unused media must be
declared. This parameter-setting operation is explained in the installation manual common to the control panel-dialler and
the stand-alone dialler: “Parameter-setting and implementation of transmission with transmission module/chapter on
“Main parameter-setting operations for the transmission module/Declaring unused media”.
Indication of power faults on power-up
Please note:
• If the main power supply has to come from the mains power module:
- a sufficiently charged Li-Ion back-up battery must be installed in case the control panel-dialler issues the voice message
“Fault, Accumulator Voltage, Control panel”, and the red LED flashes until the battery has been properly connected.
- if there is a mains power supply problem, the control-panel dialler issues the voice message “Fault, Battery Voltage, Control
panel”.
• If the main power supply comes from the BatLi22 lithium power pack:
- the Ethernet (ADSL) media will not be operational,
- the GSM/GPRS media will be operational on condition that the Li-Ion back-up battery has been installed. In this case
(powered without mains), the GSM/GPRS media will be configured by default for outgoing calls only.
If an improper power supply is used with the transmission module connected this will lead to an error indication following
power-up.
What to do if?
Red LED Voice message Solutions
Constant
rapid
flashing
“fault, power supply,
transmitter plug”
use the tables in the “Appendix/Accessories and power supplies to
be used” chapter to check compatibility between the transmission
module media and the control panel-dialler power supply.
“fault, transmitter plug” check the transmission module has been properly installed.
“fault, battery voltage,
control panel”
check the state of the main power supply: BatLi 22 lithium power
pack or mains power module depending on the case.
“fault, accumulator
voltage, control panel”
if the power supply is from the mains, check that the Li-Ion back-up
battery has been installed and is properly charged.
Media used
Control panel
without
transmission
module
Control panel with telephone transmission module/media available
SH501AX
PSTN+ Ethernet
(ADSL)
SH502AX
GSM/GPRS+
Ethernet (ADSL)
SH503AX
PSTN+GSM/GPRS+
Ethernet (ADSL)
SH504AX
Ethernet
(ADSL)
PSTN+Ethernet
(ADSL)
/
mains power
module + Li-Ion
/
mains power module + Li-Ion
/
GSM/GPRS+
Ethernet (ADSL)
/ /
mains power module
+ Li-Ion
/
PSTN+GSM/GPRS
+Ethernet (ADSL)
/ / / /
(PSTN+GSM/GPRS)
only
/ / /
• BatLi 22 + compulsory Li-Ion
or
• mains power module + Li-Ion
for GSM incoming calls
/
PSTN only /
• BatLi 22
or
• mains power
module + Li-Ion
/
• BatLi 22
or
• mains power module + Li-Ion
/
GSM/GPRS only / /
• BatLi 22 +
compulsory Li-Ion
or
• mains power module
+ Li-Ion
• BatLi 22 + compulsory Li-Ion
or
• mains power module + Li-Ion
for GSM incoming calls
/
Ethernet (ADSL) only / mains power module + Li-Ion
No remote
transmission module
BatLi 22
or mains power
module
/ / / /
