Daitsu DS-12KIDT-2 - Product Dimensions

Air Conditioner Service Manual
6
3. Product Dimensions
Indoor Unit:
Outdoor Unit:
Model
Indoor unit
Outdoor unit
A
B
C
D
E
F
G
H
I
J
K
DS-9KIDR(W)/ DOS-9KIDR(W)
777
205
250
712
498
234
415
291
225
48.5
52
DS-12KIDR(W)/ DOS-12KIDR(W)
777
205
250
712
498
234
415
291
225
48.5
52
DS-18KIDR(W)/ DOS-18KIDR(W)
910
205
292
794
602
288
516
349
314
53.9
52
DS-24KIDR(W)/ DOS-24KIDR(W)
1010
220
315
845
693
336
586
374.9
347.5
58.6
63
DS-9KIDT-2(W)/ DOS-9KIDT-2(W)
777
205
250
712
498
234
415
291
225
48.5
52
DS-12KIDT-2(W)/ DOS-12KIDT-2(W)
777
205
250
712
498
234
415
291
225
48.5
52
DS-18KIDT(W)/ DOS-18KIDT(W)
910
205
292
794
602
288
516
349
314
53.9
52
DS-24KIDT(W)/ DOS-24KIDT(W)
1010
220
315
845
693
336
586
374.9
347.5
58.6
63
