MAN# 650665:A
TACH Tachometer warning setup
• When “>TACH” is displayed, press and hold the switch until “RELEASE” is displayed, and release.
• The selectable options are “INPUT”, “HIGH WARNING”, and “BACK”.
• Press and release the switch to change the selection; press and hold the switch to select it.
INPUT Signal input setup
• This may be required to be changed for some low voltage ECM tach signals.
•
When “>INPUT” is displayed, press and hold the switch until “RELEASE” is displayed, release the switch.
•
The selections are “CYLINDER”, “TYPE”, and “BACK”.
•
Press and release the switch to change the selection: press and hold the switch to select it.
CYLINDER Cylinder count setup
When “>CYLINDER” is displayed, press and hold the switch until “RELEASE” is displayed, and release.
The cylinder options range from 1 to 16.
Press and release the switch to change the cylinder count.
Press and hold the switch until “RELEASE” is displayed, and release.
Exit setup.
TYPE Signal type setup
• When “>TYPE” is displayed, press and hold the switch until “RELEASE” is displayed, and release.
• The options are “>*12V HIGH”, “5V LOW” and “BACK”.
• Press and release the switch to change the voltage input range.
• Press and hold the switch until “RELEASE” is displayed, and release.
• Exit setup.
High warning (shift light) setup
•
When “>HIGH WARNING” is displayed, press and hold the switch until “RELEASE” is displayed, and release.
• The display will show the current high RPM warning with a *.
• The default is 5,500 RPMs but is selectable from 2,200 to 8,200 RPMs.
• Press and release the switch to change the RPM warning point.
• Press and hold the switch until “RELEASE” is displayed, and release.
• Exit setup.
OIL TEMP Engine oil temperature setup menu
• Only valid to use when optional SEN-1043 or SEN-1044 is used.
• When “>OIL TEMP” is displayed, press and hold the switch until “RELEASE” is displayed.
• The options are “UNIT”, “ON”, “OFF” and “BACK”. Factory default is “*OFF” (no temp displayed)
• Press and release to choose an option, then press and hold to select option.
When “>UNIT” is displayed, press and hold the switch until “RELEASE” is displayed, and release.
Press and release the switch to select “F”, “C” or “BACK”.
Press and hold the switch on the selection, until “RELEASE” is displayed, and release.
• The options are “UNIT”, “ON”, “OFF” and “BACK, again.
• To enable oil temp, when “>ON” is displayed, press and hold the switch until “RELEASE” is displayed, and release.
• The selections will be “SENDER”, “HIGH WARNING”, “TEST”, or “BACK”.
• Press and release the switch to change the selection, press and hold the switch to select it.
SENDER Temperature sender selection
• When “>SENDER” is displayed, press and hold the switch until “RELEASE” is displayed, and release.
• The display options are “SEN-1043”, “SEN-1044” and “BACK”.
• Press and release the switch to match to the optional sender you purchased from Dakota Digital.
• Press and hold the switch on the selection, until “RELEASE” is displayed, and release.
HIGH WARNING High oil temperature warning setup
• When “>HIGH warning” is displayed, press and hold the switch until “RELEASE” is displayed, and release.
• The display will show the default high temp warning of “>*300”.
• The high temperature warning points range from 225 to 375F, (107 to 190C).
• Press and release the switch to change the change the high temp warning point.
• Press and hold the switch until “RELEASE” is displayed, and release.
TEST Resistance test
• When “>TEST” is displayed, press and hold the switch until “RELEASE” is displayed, and release.
• The display will give a resistance (ohm) reading of the sender. An open will read -1 ohms.
• Press and release the switch to change the gauge. Press and hold the switch to exit.
• Exit setup.
