10
ENGLISH
Remove insulation so that approx. 12mm/½” of bare
wire is exposed. Press the top of the terminal down
and insert the bare wire into the opening. When the
wire is fully in place with no loose strands exposed,
release the terminal. The cable is now connected.
NOTE: The grille is very tightly fitted to the
loudspeaker to prevent rattle noise. Therefore
the grille can be difficult to mount and dis-
mount. To dismount the grille, carefully press
one end of the grille while pulling the grille
from the loudspeaker. When dismounted in one
end, carefully pull the other end of the grille. If
you cannot grip the ends, you can carefully use
an awl or a small screwdriver.
When mounting the grille, be careful not to scratch
the loudspeaker. Follow the guide for dismounting the
grille, but in reverse order.
On the inside of the grille there is a piece of non-woven. The non-woven is on the grille to protect
the drivers against dust and dirt. Therefore the non-woven must remain on the grille.
GRILLE
