3. Installation and Setup
Your DALI SOUND HUB COMPACT can be located
predominantly as is convenient for you and your home,
although it should be within the same space as the speakers
it is to be connected to. We recommend the SOUND HUB
COMPACT is placed on a furniture unit or wall-mounted
using its underside keyhole slots. However, the only
constraints are accessibili to a mains power socket and to
the signal cables for any wired audio sources that are to be
connected.
If you wish to wall-mount your SOUND HUB COMPACT
using its keyhole slots you should be sure of the suitabili
of the wall, and of your abili to securely insert a screw. If
you are unsure, it is best to seek advice. The SOUND HUB
COMPACT is best mounted in landscape orientation with its
connection panel facing downwards.
SOUND HUB COMPACT wall hanging is illustrated in
Diagram 3. Use wall-mounting screws of 3 – 5mm (0.12
– 0.20inches) shank diameter and 10mm (0.4inches)
maximum head diameter. Leave 8 – 12mm (0.30 –
0.50inches) screw length protruding from the wall surface.
• Once the preferred SOUND HUB COMPACT location has
been established, insert two mounting screws in the wall
106mm (4.2inches) apart on the SOUND HUB COMPACT
horizontal centre line.
• Li the SOUND HUB COMPACT up on to the screws so
that their heads engage with the keyhole slots. This is best
done aer all the required cables are connected to the
SOUND HUB COMPACT. See the following section for
more on SOUND HUB COMPACT connections.
NOTE:
Your SOUND HUB COMPACT can be placed inside a closed
cupboard or otherwise concealed from line of sight to its
remote control. However, in these cases it will be necessary
to connect the supplied IR Signal Receiver and position its
head in an unconcealed location.
7
