Dalla Corte mini - Control Panel and Machine Overview

25
Machine and control panel overview
1 Main switch
2 LED
3 Push-button panel
(3 switches)
4 Group head
5 Upper grill
6 Water tank 3 liter
capacity
7 Complete filter
holder
8 Steam tap
9 Steam tube
10 Cup-ret basin
11 Cups grill
12 Manometer
13 Back panel
14 Screws
15 Grill for boiler
protection
16 Temperature
regulation knob
6
5
15
1
4
8
12
9
7
10
14
3
11
13
16
P1
2
P2
2
P3
2
