INSTALL THE SUPPORT BRACKET
Install the support bracket into the window opening. Ensure that the horizontal bracket and extension arms
are located on the indoor side of the window.
INSTALLATION INSTRUCTIONS
14
Wooden Window Sill Vinyl-Clad Window Sill
For wooden window sills or fl at window sills, secure
the bracket to the window sill by drilling 1/8” pilot
holes and installing the 1/2” and 1” type A screws
as shown.
For vinyl-clad window sills, secure the bracket to
the window sill by drilling 1/8” pilot holes and
installing the 1/2” type A screws as shown.
1” Type A
1” Type A
1/2” Typ e A 1/2” Type A
1/2” Type A
1/2” Type A
To Next Page
