INSTALLATION INSTRUCTIONS
18
ANTI TIP BRACKET
The anti tip brackets must be extended into the
window track opening until. Remove the screw from
the anti tip bracket, extend it as far as it will go to
the side of the window and then secure it with the
same screw.
Warning: The anti tip brackets must be extended
into the window track opening. Failure to use
the anti tip brackets can cause serious injury or
damage.
See below for an example of what the anti tip
bracket should look like when properly installed.
Note that the side arm foam has been removed
from this images for illustration purposes.
WINDOW SEALING FOAM
Install a strip of window sealing foam to the bottom
of the lower sash to seal any small gaps between
the window and the air conditioner. Make sure the
window is completely closed and then check for
gaps. Fill any gaps with the remaining foam as
needed.
Extend the integrated window locks, located in the
U-channel, until they contact the window.
Cut the window sash foam and insert it into the
space between the upper and lower sashes.
SASH LOCK
For added security, install the optional sash lock.
Secure the sash lock in place using 1/2” type A
screws as shown.
