INSTALLATION INSTRUCTIONS
13
REQUIRED TOOLS
• Screwdrivers: Phillips and fl at head.
• Power Drill: 3.2mm (1/8”) diameter drill bit
• Pencil
• Measuring Tape
• Scissors
• Carpenter’s Level
ACCESSORIES
The following accessories are included with
the appliance and should be used during the
installation.
1. 13 mm (1/2 inch) screws (x7)
2. 9.5 mm (3/8 inch) screws (x4) (Factory installed
on some models.)
3. Safety Lock
4. Adhesive foam seal
5. Regular foam seal
6. “L” shaped mounting bracket (Factory installed
on some models.)
7. Bracket for wood windows (x2)
8. Bracket for vinyl windows (x2)
9. Weather stripping (x5)
10. Side curtains (x2)
1
2 3
4
5
6
9
8
7
10
