Danby DAC8000 - Securing Unit in Window; Securing Lower Sash

Installation Instructions
HOW TO
INSTALL (cont)
Keep a firm grip on the air conditioner, carefully place the unit into the win-
dow opening so the bottom of the air conditioner frame is against the win-
dow sill (FIG. 6 & FIG. 6A). Carefully close the window behind the top rail
of the unit.
2
Fig. 6 Fig. 6A
Bottom Rail
Inside
Window Sill
Outside
Extend the side panels out against the window frame (FIG. 7).
3
Fig. 7
4
Drive 4/5” (19 mm) locking screws through frame holes into window sash
(FIG. 8/9).
Fig. 8
Fig. 9
5
To secure lower sash in place, attach right angle sash lock with 4/5”
(19mm) screw as shown (Fig.10).
Fig. 10
7
