Danby DDW1801MW - Dishwasher Product Dimensions

Product Dimensions:
INSTALLATION REQUIREMENTS
21 1/4" (54cm)*
18" (45.7 cm)
32-1/2"
(82.5 cm) min.
35" (88.9 cm)
max
Side View
* to front of
door frame
17-1/2" (44.5 cm) min.
18" (45.7 cm) max.
Rear View
Cut-out dimensions
6"
(15.2 cm)
4"
(10.2 cm)
24"
(61 cm)
min.
34" to 35"
(86.4 cm to
88.9 cm)*
17-5/8" (44.8 cm) min.
18" (45.7 cm) max.
ALL SURFACES
MUST BE FREE
FROM INTRUSIONS
Note: ADA installation, 32-1/2” (82.5 cm) beneath 34” (86.4 cm) high countertops may be accomplished by adjust-
ing the toekick and leveling legs.
*Underside of countertop to
fl oor.
Cut holes in shaded area of
cabinet walls or fl oor for plumb-
ing and electrical service.
3
