D&H DH05A - Page 25

25
021
Signal-stopping section
1 or 2
0, 1
0
022
Consist mode F1 – F8
Reserved
023
Consist mode FL, F9 – F12
Reserved
024
Preclusion for LV
Bit 0 = F1 to bit 7 = F8
0 – 255
0
025
Preclusion for LR
See par024
0 – 255
0
026
Preclusion for AUX1
See par024
0 – 255
0
027
Preclusion for AUX2
See par024
0 – 255
0
028
Analog mode F1 – F8
Bit Function Value
0 F1 1
1 F2 2
2 F3 4
3 F4 8
4 F5 16
5 F6 32
6 F7 64
7 F8 128
0 – 255
1
029
Analog mode FL, F9 – F12
Bit Function Value
0 FL (f) 1
1 FL (r) 2
2 F9 4
3 F10 8
4 F11 16
5 F12 32
0 – 63
3
031
Interchange of track connections
0 = normal, 1 = inversed
0, 1
0
032
Interchange of motor connections
0 = normal, 1 = inversed
0, 1
0
033
Interchange of light connections
0 = normal, 1 = inversed
0, 1
0
