Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
90
Locomotive/Vehicle function decoder from firmware version 3.12
par
Name and definition Range
Standard
166 Conditions for AUX4 (see par161) 0-250 0
167 Conditions for AUX5 (see par161) 0-127 0
168 Conditions for AUX6 (see par161) 0-127 0
169
Initial mapping (not relevant to PD05A/PD06A)
Bit Function Value Bit Function Value
0........LV ................................1 4...... AUX3 .......................... 16
1........LR ................................ 2 5...... AUX4 .......................... 32
2........AUX1 ...........................4 6...... AUX5 .......................... 64
3........AUX2 ...........................8 7...... AUX6 ........................ 128
These function outputs are active as soon as the decoder is addressed
(without active function key). Thus, for example, the switchover of the sliding contacts
can be realized, in connection with the conditions.
0-255 0
401 Function interchange F1
0 = deactivated, 1 ... 28 = F1 ... F28, 29 = F0 (light)
0-29 1
402 Function interchange F2
(as par401) 0-29 2
403 Function interchange F3
(as par401) 0-29 3
404 Function interchange F4
(as par401) 0-29 4
405 Function interchange F5
(as par401) 0-29 5
406 Function interchange F6
(as par401) 0-29 6
407 Function interchange F7
(as par401) 0-29 7
408 Function interchange F8 (as par401) 0-29 8
409 Function interchange F9 (as par401) 0-29 9
