Locomotive/Vehicle function decoder from firmware version 3.12
1 Introduction
The locomotive decoders supports various data formats and operating modes:
Our decoders can be used for normal direct current motors as well for coreless motors.
The operation on alternating current supplied layouts with switching impulse is not allowed! The switching
impulse destroys the decoder (exception: DH21A/B, DH22A/B and FH22A)!
The operation of inductive consumers (decouplers, relays, etc.) requires the connection of freewheeling diodes
(see supplement 4).
Decoder SX1, SX2 DCC MM1, MM2 DC-analog AC-analog
DH05C, DH10C, DH12A, DH14B, DH16A, DH18A X X X X
DH21A/B, DH22A/B
X X X X X
FH05B, FH16A, FH18A
X X X X
FH22A X X X X X
PD05A X X
PD06A X X X
PD12A, PD18A, PD21A X X
