Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
79
Locomotive/Vehicle function decoder from firmware version 3.12
par
Name and definition Range Standard
001 Address unit position 0-99 1
002 Address hundreds digit 0-99 10
003 Address for SX1
If > 111 deactivated
0-255 112
004 Address for SX1, 1. additional channel
Functions F1-F8
0-255 1
005 Address for SX1, 2. additional channel
Functions F9-F16
0-255 0
006 Locomotive address output
1 = activated
(if suitable occupancy detectors, power packs/boosters and central units are available).
0-1 0
007 Mode of operation additional channel
0 = relativ:
1. Additional channel = par003 + par004
2. Additional channel = par003 + par005
1 = absolute
0-1 0
008 Consist address unit place
Currently without function
10.2.1 List of supported parameters
The abbreviation FH* refers to the decoder types FH05B, FH16A, FH18A and FH22A.
