Locomotive/Vehicle function decoder from firmware version 3.12
Switch off function (CV113-116, CV125-128, par024-027, par141-par144)
This function gives you the option for deactivating the output (e.g. frontal driving cab light off), despite
of activated output (e.g. L
V by function F0).
Example:
A typical situation where to apply the switch off function is the push pull operation.
The front lightning pointing to the waggon must be switched off, but the other lights must be reversed
according to the driving direction (white ↔ red).
F0 Switches the light on (white or red according to the driving direction)
F2 Switches the font light off
F3 Switches the rear ligth off
LV Front light white | LR Rear light white | AUX1 Front light red | AUX2 Rear light red
CV par Function
RG/
AUX6
ABL/
AUX5
AUX4 AUX3 AUX2 AUX1 LR LV
33 061 F0(f)
x x
34 062 F0(r)
x x
CV par
Function
F8 F7 F6 F5 F4 F3 F2 F1
113 024
LV off
x
114 025
LR off
x
115 026
AUX1 off
x
116 027
AUX2 off
x
