Par. No. # Parameter description Default value 4-set-up Change during opera-

tion

Conver-

sion index

Type

1-0* General Settings

1-00 Configuration Mode null All set-ups TRUE - Uint8

1-03 Torque Characteristics [0] Compressor CT All set-ups TRUE - Uint8

1-2* Motor Data

1-20 Motor Power [kW] ExpressionLimit All set-ups FALSE 1 Uint32

1-21 Motor Power [HP] ExpressionLimit All set-ups FALSE -2 Uint32

1-22 Motor Voltage ExpressionLimit All set-ups FALSE 0 Uint16

1-23 Motor Frequency ExpressionLimit All set-ups FALSE 0 Uint16

1-24 Motor Current ExpressionLimit All set-ups FALSE -2 Uint32

1-25 Motor Nominal Speed ExpressionLimit All set-ups FALSE 67 Uint16

1-28 Motor Rotation Check [0] Off All set-ups FALSE - Uint8

1-29

Automatic Motor Adaptation (AMA) [0] Off All set-ups FALSE - Uint8

1-3* Adv. Motor Data

1-30 Stator Resistance (Rs) ExpressionLimit All set-ups FALSE -4 Uint32

1-31 Rotor Resistance (Rr) ExpressionLimit All set-ups FALSE -4 Uint32

1-35 Main Reactance (Xh) ExpressionLimit All set-ups FALSE -4 Uint32

1-36 Iron Loss Resistance (Rfe) ExpressionLimit All set-ups FALSE -3 Uint32

1-39 Motor Poles ExpressionLimit All set-ups FALSE 0 Uint8

1-5* Load Indep. Setting

1-50 Motor Magnetisation at Zero Speed 100 % All set-ups TRUE 0 Uint16

1-51 Min Speed Normal Magnetising [RPM] ExpressionLimit All set-ups TRUE 67 Uint16

1-52 Min Speed Normal Magnetising [Hz] ExpressionLimit All set-ups TRUE -1 Uint16

1-6* Load Depen. Setting

1-60 Low Speed Load Compensation 100 % All set-ups TRUE 0 Int16

1-61 High Speed Load Compensation 100 % All set-ups TRUE 0 Int16

1-62 Slip Compensation 0 % All set-ups TRUE 0 Int16

1-63 Slip Compensation Time Constant 0.10 s All set-ups TRUE -2 Uint16

1-64 Resonance Dampening 100 % All set-ups TRUE 0 Uint16

1-65 Resonance Dampening Time Constant 5 ms All set-ups TRUE -3 Uint8

1-7* Start Adjustments

1-71 Start Delay 00.0 s All set-ups TRUE -1 Uint16

1-72 Start Function [2] Coast All set-ups TRUE - Uint8

1-73 Flying Start [0] Disabled All set-ups FALSE - Uint8

1-74 Start Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16

1-75 Start Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16

1-76 Start Current 0.00 A All set-ups TRUE -2 Uint32

1-77 Compressor Start Max Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16

1-78 Compressor Start Max Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16

1-79 Compressor Start Max Time to Trip 5.0 s All set-ups TRUE -1 Uint8

1-8* Stop Adjustments

1-80 Function at Stop [0] Coast All set-ups TRUE - Uint8

1-81 Min Speed for Function at Stop [RPM] ExpressionLimit All set-ups TRUE 67 Uint16

1-82 Min Speed for Function at Stop [Hz] ExpressionLimit All set-ups TRUE -1 Uint16

1-86 Compressor Min. Speed for Trip [RPM] ExpressionLimit All set-ups TRUE 67 Uint16

1-87 Compressor Min. Speed for Trip [Hz] ExpressionLimit All set-ups TRUE -1 Uint16

1-9* Motor Temperature

1-90 Motor Thermal Protection [0] No protection All set-ups TRUE - Uint8

1-91 Motor External Fan [0] No All set-ups TRUE - Uint16

1-93 Thermistor Source [0] None All set-ups TRUE - Uint8

6.2.2 1-** Load / Motor

6 How to Programme the Frequency Converter ADAP-KOOL

Drive AKD 102 High Power

100

MG.11.O1.02 - ADAP-KOOL

is a registered Danfoss trademark
