Danfoss ADAP-KOOL AKD 102

Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
8-0* General Settings 8-01 Control Site null All set-ups TRUE - Uint8 8-02 Control Source null All set-ups TRUE - Uint8
8-03 Control Timeout Time ExpressionLimit 1 set-up TRUE -1 Uint32
8-04 Control Timeout Function [0] Off 1 set-up TRUE - Uint8
8-05 End-of-Timeout Function [1] Resume set-up 1 set-up TRUE - Uint8
8-06 Reset Control Timeout [0] Do not reset All set-ups TRUE - Uint8
8-07
Diagnosis Trigger [0] Disable 2 set-ups TRUE - Uint8
8-1* Control Settings 8-10 Control Profile [0] FC profile All set-ups TRUE - Uint8 8-13 Configurable Status Word STW [1] Profile Default All set-ups TRUE - Uint8 8-3* FC Port Settings 8-30 Protocol [0] FC 1 set-up TRUE - Uint8 8-31 Address ExpressionLimit 1 set-up TRUE 0 Uint8 8-32 Baud Rate null 1 set-up TRUE - Uint8
8-33 Parity / Stop Bits null 1 set-up TRUE - Uint8
8-35 Minimum Response Delay ExpressionLimit 1 set-up TRUE -3 Uint16
8-36 Maximum Response Delay ExpressionLimit 1 set-up TRUE -3 Uint16
8-37 Maximum Inter-Char Delay ExpressionLimit 1 set-up TRUE -5 Uint16 8-4* Adv. Protocol Set. 8-40 Telegram Selection [1] Standard telegram 1 2 set-ups TRUE - Uint8 8-45 BTM Transaction Command [0] Off All set-ups FALSE - Uint8 8-46 BTM Transaction Status [0] Off All set-ups TRUE - Uint8
8-47
BTM Timeout 60 s 1 set-up FALSE 0 Uint16
8-5* Digital/Bus 8-50 Coasting Select [3] Logic OR All set-ups TRUE - Uint8 8-52 DC Brake Select [3] Logic OR All set-ups TRUE - Uint8
8-53 Start Select [3] Logic OR All set-ups TRUE - Uint8
8-54 Reversing Select null All set-ups TRUE - Uint8
8-55 Set-up Select [3] Logic OR All set-ups TRUE - Uint8
8-56 Preset Reference Select [3] Logic OR All set-ups TRUE - Uint8 8-7* BACnet 8-70 BACnet Device Instance 1 N/A 1 set-up TRUE 0 Uint32 8-72 MS/TP Max Masters 127 N/A 1 set-up TRUE 0 Uint8 8-73 MS/TP Max Info Frames 1 N/A 1 set-up TRUE 0 Uint16
8-74 "I-Am" Service [0] Send at power-up 1 set-up TRUE - Uint8
8-75 Initialisation Password ExpressionLimit 1 set-up TRUE 0 VisStr[20] 8-8* FC Port Diagnostics 8-80 Bus Message Count 0 N/A All set-ups TRUE 0 Uint32 8-81 Bus Error Count 0 N/A All set-ups TRUE 0 Uint32 8-82 Slave Message Count 0 N/A All set-ups TRUE 0 Uint32
8-83
Slave Error Count 0 N/A All set-ups TRUE 0 Uint32
8-9* Bus Jog / Feedback 8-90 Bus Jog 1 Speed 100 RPM All set-ups TRUE 67 Uint16 8-91 Bus Jog 2 Speed 200 RPM All set-ups TRUE 67 Uint16
8-94 Bus Feedback 1 0 N/A 1 set-up TRUE 0 N2
8-95 Bus Feedback 2 0 N/A 1 set-up TRUE 0 N2
8-96 Bus Feedback 3 0 N/A 1 set-up TRUE 0 N2
6.2.8 8-** Communication and Options
6 How to Programme the Frequency Converter ADAP-KOOL
®
Drive AKD 102 High Power
108 MG.11.O1.02 - ADAP-KOOL
®
is a registered Danfoss trademark
6
