1) AUX Relay 5) Brake
01 02 03 -R +R
04 05 06 81 82
2) Temp Switch 6) SMPS Fuse (see fuse tables for part number)
106 104 105 7) AUX Fan
3) Line 100 101 102 103
R S T L1 L2 L1 L2
91 92 93 8) Fan Fuse (see fuse tables for part number)
L1 L2 L3 9) Mains ground
4) Load sharing 10) Motor
-DC +DC U V W
88 89 96 97 98
T1 T2 T3
Illustration 4.5: Position of earth terminals IP00, frame sizes
D
Illustration 4.6: Position of earth terminals IP21 (NEMA type
1) and IP54 (NEMA type 12)
NB!
D2 and D4 shown as examples. D1 and D3 are equivalent.
4 Electrical Installation ADAP-KOOL
®
Drive AKD 102 High Power
36
MG.11.O1.02 - ADAP-KOOL
®
is a registered Danfoss trademark
