[21] Speed up For digital control of the up/down speed is desired (motor potentiometer). Activate this function by
selecting either Freeze reference or Freeze output. When Speed up is activated for less than 400
msec. the resulting reference will be increased by 0.1 %. If Speed up is activated for more than 400
msec. the resulting reference will ramp according to Ramp 1 in par.3-41
Ramp 1 Ramp Up Time
.
[22] Speed down Same as Speed up [21].
[23] Set-up select bit 0 Selects one of the four set-ups. Set par. 0-10 to Multi Set-up.
[24] Set-up select bit 1 Same as Set-up select bit 0 [23].
(Default Digital input 32)
[34] Ramp bit 0 Select which ramp to use. Logic “0” will select ramp 1 while logic “1” will select ramp 2.
[36] Mains failure inverse Select to activate function selected in par. 14-10
Mains Failure
. Mains failure is active in the Logic
“0” situation.
[39] Day/ Night Control
[52] Run Permissive The input terminal, for which the Run permissive has been programmed must be logic “1” before a
start command can be accepted. Run permissive has a logic ‘AND’ function related to the terminal
which is programmed for
START
[8],
Jog
[14] or
Freeze Output
[20], which means that in order to
start running the motor, both conditions must be fulfilled. If Run Permissive is programmed on
multiple terminals, Run permissive needs only be logic ‘1’ on one of the terminals for the function
to be carried out. The digital output signal for Run Request (
Start
[8],
Jog
[14] or
Freeze output
[20]) programmed in par. 5-3*, or par. 5-4*, will not be affected by Run Permissive.
[53] Hand start A signal applied will put the frequency converter into Hand mode as if button
Hand On
on the LCP
has been pressed and a normal stop command will be overridden. If disconnecting the signal, the
motor will stop. To make any other start commands valid, another digital input must be assign to
Auto Start
and a signal applied to this. The
Hand On
and
Auto On
buttons on the LCP has no impact.
The
Off
button on the LCP will override
Hand Start
and
Auto Start
. Press either the
Hand On
or
Auto
On
button to make
Hand Start
and
Auto Start
active again. If no signal on neither
Hand Start
nor
Auto Start
, the motor will stop regardless of any normal Start command applied. If signal applied
to both
Hand Start
and
Auto Start
, the function will be
Auto Start
. If pressing the
Off
button on the
LCP the motor will stop regardless of signals on
Hand Start
and
Auto Start
.
[54] Auto start A signal applied will put the frequency converter into Auto mode as if the LCP button
Auto On
has
been pressed. See also
Hand Start
[53]
[55] DigiPot Increase Uses the input as an INCREASE signal to the Digital Potentiometer function described in parameter
group 3-9*
[56] DigiPot Decrease Uses the input as a DECREASE signal to the Digital Potentiometer function described in parameter
group 3-9*
[57] DigiPot Clear Uses the input to CLEAR the Digital Potentiometer reference described in parameter group 3-9*
[62] Reset Counter A Input for reset of counter A.
[63] Counter B (up) (Terminal 29 and 33 only) Input for increment counting in the SLC counter.
[65] Reset Counter B Input for reset of counter B.
[66] Sleep Mode Forces frequency converter into Sleep Mode (see par. 22-4*).
[78] Reset Preventive Maintenance Word Resets all data in par. 16-96
Maintenance Word
to 0.
[120] Lead Pump Start Starts/ stops the lead pump (controlled by AKD 102).
[130] Comp. 1 Interlock The input signal must be low before the AKD 102 is able to start compressor 1.
[131] Comp. 2 Interlock The input signal must be low before the AKD 102 is able to start compressor 2.
[132] Comp. 3 Interlock The input signal must be low before the AKD 102 is able to start compressor 3.
[139] Comp. 1 Inv. Interlock The input signal must be high before the AKD 102 is able to start compressor 1.
[140] Comp. 2 Inv. Interlock The input signal must be high before the AKD 102 is able to start compressor 2.
[141] Comp. 3 Inv. Interlock The input signal must be high before the AKD 102 is able to start compressor 3.
