[1835] Analog Out X42/11 [V] Shows the value of the signal applied to terminal X42/11 on the Analog I/O card.
[2117] Ext. 1 Reference [Unit] The value of the reference for extended Closed Loop Controller 1
[2118] Ext. 1 Feedback [Unit] The value of the feedback signal for extended Closed Loop Controller 1
[2119] Ext. 1 Output [%] The value of the output from extended Closed Loop Controller 1
[2137] Ext. 2 Reference [Unit] The value of the reference for extended Closed Loop Controller 2
[2138] Ext. 2 Feedback [Unit] The value of the feedback signal for extended Closed Loop Controller 2
[2139] Ext. 2 Output [%] The value of the output from extended Closed Loop Controller 2
[2157] Ext. 3 Reference [Unit] The value of the reference for extended Closed Loop Controller 3
[2158] Ext. 3 Feedback [Unit] The value of the feedback signal for extended Closed Loop Controller 3
[2159] Ext. 3 Output [%] The value of the output from extended Closed Loop Controller 3
[2230] No-Flow Power The calculated No Flow Power for the actual operating speed
[2580] Pack Status Status for the operation of the Pack Controller
[2581] Compressor Status Status for the operation of each individual compressor controlled by the Pack Controller
0-21 Display Line 1.2 Small
The options are the same as those listed for par 0-20
Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1, middle position.
[1614] * Motor Current [A]
0-22 Display Line 1.3 Small
The options are the same as those listed for par 0-20
Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1, right position.
[1610] * Power [kW]
0-23 Display Line 2 Large
The options are the same as those listed for par 0-20
Display Line 1.1 Small
Option: Function:
Select a variable for display in line 2.
[1613] * Frequency [Hz]
0-24 Display Line 3 Large
The options are the same as those listed for par 0-20
Display Line 1.1 Small
Option: Function:
Select a variable for display in line 3.
[1502] * Counter [kWh]
0-37 Display Text 1
Range: Function:
0 N/A* [0 - 0 N/A] In this parameter it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If to be displayed permanently select Display Text 1 in par. 0-20
Display
Line 1.1 Small
, par. 0-21
Display Line 1.2 Small
, par. 0-22
Display Line 1.3 Small
, par. 0-23
Display
Line 2 Large
or par. 0-24
Display Line 3 Large
. Use the
▲
or
▼
buttons on the LCP to change a
character. Use the
◀
and
▶
buttons to move the cursor. When a character is highlighted by the
cursor, it can be changed. Use the
▲
or
▼
buttons on the LCP to change a character. A character
can be inserted by placing the cursor between two characters and pressing
▲
or
▼
.
