[101] Reference Min-Max : Minimum reference - Maximum reference, (0-20 mA)
[102] Feedback +-200% : -200% to +200% of par. 20-14
Maximum Reference/Feedb.
, (0-20 mA)
[103] Motor cur. 0-Imax : 0 - Inverter Max. Current (par. 16-37
Inv. Max. Current
), (0-20 mA)
[104] Torque 0-Tlim : 0 - Torque limit (par. 4-16
Torque Limit Motor Mode
), (0-20 mA)
[105] Torque 0-Tnom : 0 - Motor rated torque, (0-20 mA)
[106] Power 0-Pnom : 0 - Motor rated power, (0-20 mA)
[107] * Speed 0-HighLim : 0 - Speed High Limit (par.4-13
Motor Speed High Limit [RPM]
and par.4-14
Motor Speed High Limit
[Hz]
), (0-20 mA)
[113] Ext. Closed Loop 1 : 0 - 100%, (0-20 mA)
[114] Ext. Closed Loop 2 : 0 - 100%, (0-20 mA)
[115] Ext. Closed Loop 3 : 0 - 100%, (0-20 mA)
[130] Out frq 0-100 4-20mA : 0 - 100 Hz
[131] Reference 4-20mA : Minimum Reference - Maximum Reference
[132] Feedback 4-20mA : -200% to +200% of par. 20-14
Maximum Reference/Feedb.
[133] Motor cur. 4-20mA : 0 - Inverter Max. Current (par. 16-37
Inv. Max. Current
)
[134] Torq.0-lim 4-20 mA : 0 - Torque limit (par. 4-16
Torque Limit Motor Mode
)
[135] Torq.0-nom 4-20mA : 0 - Motor rated torque
[136] Power 4-20mA : 0 - Motor rated power
[137] Speed 4-20mA : 0 - Speed High Limit (4-13 and 4-14)
[139] Bus ctrl. : 0 - 100%, (0-20 mA)
[140] Bus ctrl. 4-20 mA : 0 - 100%
[141] Bus ctrl t.o. : 0 - 100%, (0-20 mA)
[142] Bus ctrl t.o. 4-20mA : 0 - 100%
[143] Ext. CL 1 4-20mA : 0 - 100%
[144] Ext. CL 2 4-20mA : 0 - 100%
[145] Ext. CL 3 4-20mA : 0 - 100%
NB!
Values for setting the Minimum Reference is found in open loop par.3-02
Minimum Reference
and for closed loop par. 20-13
Minimum Reference/
Feedb.
- values for maximum reference for open loop is found in par.3-03
Maximum Reference
and for closed loop par. 20-14
Maximum Reference/
Feedb.
.
6-51 Terminal 42 Output Min Scale
Range: Function:
0.00 %* [0.00 - 200.00 %] Scale for the minimum output (0 or 4 mA) of the analogue signal at terminal 42.
Set the value to be the percentage of the full range of the variable selected in par.6-50
Terminal
42 Output
.
6 How to Programme the Frequency Converter ADAP-KOOL
®
Drive AKD 102 High Power
86
MG.11.O1.02 - ADAP-KOOL
®
is a registered Danfoss trademark
6
