Danfoss Heating
5
2. Before attaching the sensor to the cylinder using the strap
provided, connect a 2-core cable to the sensor to allow
interconnection to the thermostat setting unit.
3. Apply the contact paste provided to the part of the sensor
in contact with the cylinder and clamp the sensor to the
cylinder wall.
A spacer piece is provided for use with cylinders that have
thick insulation (see page 6).
4. Mount the thermostat wallplate on to a wall next to the
cylinder. Connect the cable from the sensor to terminals 1
& 2 of the wallplate (see wiring diagram on page 7).
5. Now mount the thermostat setting unit onto the wallplate
(see diagrams on page 9).
