4 Transport, unpacking and setting-up
4.1 Transporting the heat pump
Caution! During transportation or lifting of the entire heat pump, the front panel must always be installed
as it locks the other panels construction.
Caution! The heat pump must always be transported and stored in a dry area. Secure the heat pump so
that it cannot tip over during transportation.
When transporting indoors to the installation location it may be necessary to place the heat pump on its back. The
time that the heat pump is transported on its back should be as short as possible. After the heat pump has been
lifted up again it must stand upright for at least an hour before commissioning.
4.2 Unpacking heat pump
4.2.1 Delivery check
1. Check that there is no transport damage. The heat pump is packaged in cardboard.
2. Remove the packaging and check that the delivery contains the following components.
Part number 4-10 kW 12-16 kW
Safety valve 9 bar 1/2" 086U2369 1 1
Safety valve 1.5 bar 1/2" 086U0896 1 1
Outdoor sensor 086U2701 1 1
Expansion and bleed tank 086U2824 1 1
Rubber bellows for 22-28 mm hole 086U3423 5 5
Flexible hose R20 L=550 086U6033 2 -
Flexible hose R25 L=550 086U6034 - 2
Filler device DN25 086U6006 1 -
Filler device DN32 086U6007 - 1
Dirt filter with shut-off DN20 086U3427 1 -
Dirt filter with shut-off DN25 086U6005 - 1
Manual holder 086U3988 1 1
4.3 Setting-up the heat pump
4.3.1 Recommended location
Caution! To avoid condensation problems for the brine lines, as short a brine line as possible is
recommended indoors.
The heat pump should be located on a stable floor, preferably made of concrete. When locating the heat pump on
a wooden floor this should be reinforced to take the weight of the heat pump including a filled water heater, see
technical data for relevant heat pump. One solution is to place a thick metal plate, at least 6mm, under the heat
pump. The metal plate should cover several joists spreading the weight of the heat pump over a larger area. If the
heat pump is being installed in a newly-built house, this has normally been taken into account during construc-
tion, and the joists where the heat pump will be located have been reinforced. Always check that this has been
carried out when installing into a newly-built house.
Installation instructions VMBMA1002 – 15
