Danfoss DP250 User Manual

44
11032748_Rev DA_Sep2014
User Manual EIC-Engine Information Center – DP2xx
Connection/Pinout settings
Related Parts & Kits
DP200 Series Related Products Part Numbers
10100944 Deutsch Mating Connector Bag Assembly (20-24 AWG)
10102025 Deutsch Mating Connector Bag Assembly (16-20 AWG)
Electrical Connection Kits
10100944 12-pin Deutsch connection Kit
Contents:
10100738 DTM06-12SA 12-pin Deutsch connector
10100743 Deutsch terminal
10100741 WM 12S locking plug
Connection Tools
10100744 Deutsch stamped contacts terminal crimp tool, size 20
10100745 Deutsch solid contacts terminal crimp tool

Danfoss DP250 Specifications

General

Brand	Danfoss
Model	DP250
Category	Touch terminals
Language	English
