Danfoss EKC 313 - Example

EKC 313 User Guide RS8FZ402 © Danfoss 2015-07 3
Example
Optimised superheat regulation with limit if the condensing pressure is low.
Optimised superheat regulation is used when the condensing
pressure is above the set value.
If the condensing pressure falls below the set value, the opti-
mised superheat regulation ceases and the ETS valve closes
gradually until the pressure rises above the value.
