Danfoss EKC 313 User Manual

4 User Guide RS8FZ402 © Danfoss 2015-07 EKC 313
Function overview
Function Para-
meter
Parameter by operation via
data communication
Normal display
Displays either the valve's actual opening degree or the actual superheat value.
(Desired value can be set in o17)
Briey pushing the bottom button will display one of the two readings.
Briey pushing both buttons will display the superheat reference (u22).
u24 /
u21
Valve OD %
SH
Control parameters Injection control
Start/stop of regulation
This setting can be used to start and stop regulation.
r12 Main Switch
I: Integration time Tn
If the Tn value is increased the regulation becomes slower
n05 Tn sec.
Lower limit value for the condensing pressure.
If the pressure falls, the valve will start closing.
n98 Tc Ref
Max. opening degree
The valve's opening degree can be limited here.
The setting is expressed as a % of the total opening degree. The voltage signal of 0-10
V on the output will be limited correspondingly.
n32 OD% Max
Amplication factor for the superheat
This setting determines the valve’s opening degree as a function of the change in
evaporating pressure. An increase of the evaporating pressure will result in a reduced
opening degree. When there is a drop-out on the low-pressure thermostat during
start-up the value must be raised a bit. If there is pendling during start-up the value
must be reduced a little.
The value should only be changed by specially trained sta.
n20 Kp T0
Kp value for amplication factor for PID regulation n95 Kp Max
Kp value near reference value
Just around the reference this value will be used in stead of the "n95 value"
The value should only be changed by specially trained sta.
n19 Kp Min
Signal safety during start-up
The control function uses the value as start value for the valve’s opening degree at
each thermostat cutin. By adaptive control the controller continuously calculates a
new value.
The value should only be changed by specially trained sta.
n17 Start OD%
Start-up time for safety signal
If the controller does not obtain a reliable signal within this period of time the con-
troller will in other ways try to establish a stable signal. (A too high value may result in
a ooded evaporator).
The value should only be changed by specially trained sta.
n15 StartUp time
MOP
If no MOP function is required, select pos. O. (A value of max. (60) will correspond to
O)
n11 MOP (bar)
Min. value for the superheat reference n10 SH Min
Max. value for the superheat reference n09 SH Max
D: Dierentiation time Td n06 Td sec
