Apart from wizard setup, users can also use the following section which describes quick parameter
settings for general applications.
Quick guide for parameter selection
Make sure that main switch is OFF before changing
the settings. The setting will depend on the system
requirement.
Parameter: R012 Main Switch
Select predefined Danfoss valve type ETS, ETS C, KVS,
KVS C, CCM, CCMT, CTR, or user defined.
Parameter: I067 Valve configuration
Analog signal type
e.g 1- 5V / 0 - 10V.
Parameter I033 Driver
reference configuration,
I034 Ext ref voltage low,
I035 Ext ref. voltage high
Start : Main switch= Off
Select valve type
Application mode
Driver- Controller
Select how you want to use EKE: driver or superheat
controller.
Parameter: R102 Operation mode
Select Refrigerant
Select Pressure transmitter
Define Min/Max Pressure
Select Superheat Control
Set Min/Max Ref value
Select Other features
Finish: main switch = ON
Select the predefined refrigerant .
Parameter: O030 Refrigerant
Select Pressure transmitter type –AKS 32R, Sensata
112CP, OEM Ratio, NSK, AKS 32 1 - 5 V,
OEM Voltage, Bus shared
Parameter: I085 - Pe transmitter configuration.
Check parameter list for other sensors.
Define min and max Pressure transmitter in barg.
Parameter: O020 - Pe min., O021 Pe max., Check
parameter list for other sensors.
Select application control type SH control. 1: MSS,
2: LoadAp, 3: Fixed, 4: Delta SH.
Parameter: N021 SH reference mode.
Set the value for the selected control min./max.
superheat reference.
Parameter N009 SH max., N010 - SH min.
Optional – Force start up, MOP, LOP, Alarm,
Thermostat function.
Check parameter list for details.
Remember to turn on main switch to start ‘ON’ .
Parameter R012 Main switch.
Driver Controller
Select Temperature sensor
Select Temperature sensor type: EKS, ACCPBT, MBT,
Sensata 112CP, Bus shared
Parameter: I081 - S2 sensor configuration.
Check parameter list for other sensors.
To Next Page
