VISUS14F Danfoss Heating Solutions4
TS710 & FP720
1. Installation Steps
User Guide can be downloaded from: heating.danfoss.com.
1. Installation must be done by an authorised
electrician.
2. Remove and mount timer back plate direct to wall
or on wall box, and wire as required for application,
see g. 1 & 2.
3. Locate hooks at top of timer into top of back plate,
lower into position and tighten retaining screws.
2. Dimensions and Wiring
Dimensions, see g. 3. Wiring diagram, see g. 4.
Installation Guide
EN
