Danfoss FP975 User Manual

10
Wiring
NOTES:
FOR SET2E
LINK
TERMINALS 1 &
5
FP975 ON A
SET
WALLPLATE
Wiring
Always switch off mains fi rst and never fi t programmer
to a live wallplate.
For Wiring
Conversion
tables
see pages
12-19
230 Vac Fully Pumped System - Two 2-port Zone Valves
with Aux. Sw. PUMPED switch selection
N L 1 2 3 4 5 6
N
L
BOILER
PUMP
ATC
DHW
VALVE
HTG VALVE
RMT
Earths not
shown. Ensure
continuity
throughout
MAINS
fused 3A
DHW
ON
DHW
OFF
DHW
COM
HTG
ON
HTG
OFF
HTG
COM
HEAT
PLAN
For 230 Vac
systems link
L, 2 & 5
230
Vac
