Accessories
Cables code numbers
Feature Wire colors
Length Code number
Connector pin 1 pin 2 pin 3 pin 4 pin 5 pin 6
Deutsch
4 pin white blue yellow red — — 4 m 11007498
6 pin white blue yellow red black green 4 m 11007513
AMP
4 pin white blue yellow red — — 4 m 157B4994
6 pin white red black yellow green blue 5 m 157B4974
AMP/black coding 4 pin white blue yellow red — — 4 m 157B4995
Connector code numbers
Part number Name
157B4992 AMP CONNECTING KIT (GREY) 4 pin with housing, contact and wire sealing
157B4993 AMP CONNECTING KIT (BLACK) 4 pin with housing, contact and wire sealing
984L3165 EL-PLUG, ON-OFF black Hirschmann DIN connector set*
Set of seals code numbers
Part number Name Actuator
157B4997 Set of seals PVE for PVG 32/ PVG 100
155G8519 Set of seals PVE for PVG 120
11061235 Set of seals PVHC for PVG 32/ PVG 100
