RET1001M Room Thermostat
1. Installation Steps
1. Installation must be done by an authorised
electrician.
2. The room thermostat should be installed at approx.
1.5 m above oor and where the eects of sunlight,
draught or other heat sources (eg. TV’s) are avoided,
see g. 1.
3. To access wiring terminals loosen screws, remove
front cover and carefully pull o thermostat dial,
see g 2.
4. After mounting and wiring replace dial. Front cover
must be angled at the top to accept retaining tabs
and carefully lowered into position before tighten-
ing screws, see g 3.
2. Dimensions and Wiring
See g. 4 for dimensions and g. 5 for wiring diagram.
