InstallationGuideTermixVMTD-F-B
5.0Design
5.1Design
Yoursubstationmightlookdifferentthanthesubstationshown.
Designdescription
B
Heatexchanger,DHW
14
Sensorpocket,energymeter
O
Termixsensoraccelerator
31
Differentialpressurecontroller
7
Thermostaticvalve,DHW
41A
Fittingpiece,coldwatermains
9
Strainer
41BFittingpiece,energymeter
8
DEN-GT
VI.CW.C3.02/LUK40110
DanfossDistrictEnergy
