Danfoss Termix VMTD-F-B Installation Guide

InstallationGuideTermixVMTD-F-B
5.2Schematicdiagram
DHW
CWM
DCW
DH
Supply
HE
Supply
DH
Return
HE
Return
Yoursubstationmightlookdifferentthantheschematicdiagramshown.
Schematicdescription
B
Heatexchanger,DHW
31
Differentialpressurecontroller
7
Thermostaticvalve,DHW
41A
Fittingpiece,coldwatermains
9
Strainer
41BFittingpiece,energymeter
14
Sensorpocket,energymeter
DHW:DomesticHotWater
CWM:
ColdWaterMains
DCW:
DomesticColdWater
DHSupply:DistrictHeatingSupply
DHReturn:DistrictHeatingReturn
HESupply:HeatingSupply
HEReturn:HeatingReturn
5.2.1Technicalparameters
Technicalparameters
Nominalpressure:PN10(PN16versionsareavailableonenquiry)
Max.DHsupplytemperature:
120°C
Min.DCWstaticpressure:
0.5bar
Brazingmaterial(HEX):
Copper
Heatexchangerstestpressure:30bar
Soundlevel:≤55dB
DanfossDistrictEnergy
VI.CW.C3.02/LUK40110
DEN-GT
9
