Danfoss TS710 Installation Guide

VISUS14F Danfoss Heating Solutions4
TS710 & FP720
1. Installation Steps
User Guide can be downloaded from: heating.danfoss.com.
1. Installation must be done by an authorised
electrician.
2. Remove and mount timer back plate direct to wall
or on wall box, and wire as required for application,
see g. 1 & 2.
3. Locate hooks at top of timer into top of back plate,
lower into position and tighten retaining screws.
2. Dimensions and Wiring
Dimensions, see g. 3. Wiring diagram, see g. 4.
Installation Guide
EN

Danfoss TS710 Specifications

General

Mounting	DIN rail
Number of channels	1
Protection class	IP20
Switching capacity	16A
Ambient temperature range	-10°C to +55°C
