Chapter 6 Fault diagnosis and solutions VFD500 high performance vector control frequency inverter user manual
! The fault code is used for the communication read fault type: when the communication reads
the registers r25.00, r26.00, r26.08, r26.16, the register contents of the reply are fault coded.
6.2 Warning type
The warning is used to remind and inform the user of the current state of the inverter. When the warning
occurs, the keypad will display a warning message, and the warning will automatically reset when the
warning is cleared. Some warnings require the user to check the cause before running the drive, and
some do not care. Warning As an instant reminder, the drive does not store the corresponding
information.
Bit 12 of r27.10 indicates whether there is a warning message currently.
! The warning code is used for the communication read warning type: when the communication
reads register r25.16, the contents of the returned register are the warning code.
PID feedback
lost during
running
1.
PID feedback<P40.35
setting value and P40.36 not
zero,PID feedback>P40.37
setting value and P40.38 not
1.
Check PID feedback
signal
2.
P40.35 and P40.37
set correct parameter
1: The signal of user-defined
fault 1 is
input via DI.
2:The signal of user-defined fault
1 is
input via virtual I/O.
1: Reset the operation.
2: Reset the operation
1: The signal of user-defined
fault 2 is
input via DI.
2:The signal of user-defined fault
2 is
input via virtual I/O.
1: Reset the operation.
2: Reset the operation
1 : T h e D C l i n k v o l t a g e i s
insufficient and cannot be
started normally.
1:Check if the inverter power
supply is normal.
1: The parameter settings are
wrong, such as:
The torque mode is set in the
VF control mode.
1:Modify and check the
parameter compatibility
problem
1. The system is in a sleep state,
a n d t h e s y s t e m w i l l
a u t o m a ti c a l l y s t a r t w he n
hibernation is over.
1:Generally no need to pay
attention to it
