Danfoss VLT 2000 Series User Manual

MG.20.B6.02 – VLT is a registered Danfoss trademark
VLT
®
2000 Series
14
Quick Setup
If you are familiar with a VLT
If you know the VLT and how to move round in the
menus and parameters, you can go directly to steps
1-9 overleaf to get started.
Quick Set
If you are not familiar with a VLT
If you have never operated a VLT frequency converter
before, you can learn it on the basis of the
instructions on page 15.
Connection example
■
A simple connection example
In the figure below you can see a simple connection
example based on the Quick Setup programming
overleaf.
After installation
■
■

Danfoss VLT 2000 Series Specifications

General

Output Voltage	0 to Input Voltage
Control Method	V/Hz
Communication Protocols	RS-485
Enclosure Type	IP20
Operating Temperature	-10°C to +40°C
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Ambient Temperature Range	-10°C to +40°C
Input Voltage	1 x 200 - 240 VAC, 3 x 200 - 240 VAC, 3 x 380 - 480 VAC
Cooling Method	Forced air cooling
