Logic and [2]
Dig. input
Ser. port Function
0 0 DC braking
0 1 Motor running
1 0 Motor running
1 1 Motor running
Logic or [3]
Dig. input
Ser. port Function
0 0 DC braking
0 1 DC braking
1 0 DC braking
1 1 Motor running
505 Start
(START SELECT)
Value:
Digital input (DIGITAL INPUT) [0]
Serial port (SERIAL PORT) [1]
Logic and (LOGIC AND) [2]
Logic or (LOGIC OR) [3]
Function:
See function description for parameter 502 Coasting
stop.
Description of choice:
The table below shows when the motor has stopped
and when the variable frequency drive has a start com-
mand when each of the following is selected: Digital
input [0], Serial port [1], Logic and [2] or Logic or [3].
Digital input [0]
Dig. input
Ser. port Function
0 0 Stop
0 1 Stop
1 0 Start
1 1 Start
Serial port [1]
Dig. input
Ser. port Function
0 0 Stop
0 1 Start
1 0 Stop
1 1 Start
Logic and [2]
Dig. input
Ser. port Function
0 0 Stop
0 1 Stop
1 0 Stop
1 1 Start
Logic or [3]
Dig. input
Ser. port Function
0 0 Stop
0 1 Start
1 0 Start
1 1 Start
506 Reverse
(REVERSE SELECT)
Value:
Digital input (DIGITAL INPUT) [0]
Serial port (SERIAL PORT) [1]
Logic and (LOGIC AND) [2]
Logic or (LOGIC OR) [3]
Function:
See function description for parameter 502 Coasting
stop.
Description of choice:
The table below shows when the motor is running
clockwise and counter-clockwise when each of the fol-
lowing is selected: Digital input [0], Serial port [1], Logic
and [2] or Logic or [3].
Digital input [0]
Dig. input
Ser. port Function
0 0 Clockwise
0 1 Clockwise
1 0 Counter-clockwise
1 1 Counter-clockwise
Serial port [1]
Dig. input
Ser. port Function
0 0 Clockwise
0 1 Counter-clockwise
1 0 Clockwise
1 1 Counter-clockwise
VLT
®
2800 Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
