319 Analogue output terminal 42
(AO 42 FUNCTION)
Value:
No function (NO OPERATION) [0]
External reference min.-max. 0-20 mA
(ref min-max = 0-20 mA) [1]
External reference min.-max. 4-20 mA
(ref min-max = 4-20 mA) [2]
Feedback min.-max. 0-20 mA
(fb min-max = 0-20 mA) [3]
Feedback min.-max. 4-20 mA
(fb min-max = 4-20 mA) [4]
Output frequency 0-max 0-20 mA
(0-fmax = 0-20 mA) [5]
Output frequency 0-max 4-20 mA
(0-fmax = 4-20 mA) [6]
Output current 0-I
INV
0-20 mA
(0-iinv = 0-20 mA) [7]
Output current 0-I
IINV
4-20 mA
(0-iinv = 4-20 mA) [8]
Output power 0-P
M,N
0-20 mA
(0-Pnom = 0-20 mA) [9]
Output power 0-P
M,N
4-20 mA
(0-Pnom = 4-20 mA) [10]
Inverter temperature 20-100 °C 0-20 mA
(TEMP 20-100 C=0-20 mA) [11]
Inverter temperature 20-100 °C 4-20 mA
(TEMP 20-100 C=4-20 mA) [12]
Function:
The analogue output can be used for stating a process
value. It is possible to choose two types of output sig-
nals 0 - 20 mA or 4 - 20 mA.
If used as a voltage output (0 - 10 V), a pull-down re-
sistor of 500  must be fitted to common (terminal 55).
If the output is used as a current output the resulting
resistance from the equipment connected may not ex-
ceed 500 .
Description of choice:
No function. Is selected if the analogue output is not to
be used.
External Ref
MIN
- Ref
MAX
0-20 mA/4-20 mA.
An output signal is obtained, which is proportional to
the resulting reference value in the interval Minimum
reference, Ref
MIN
- Maximum reference, Ref
MAX
(pa-
rameters 204/205).
FB
MIN
-FB
MAX
0-20 mA/ 4-20 mA.
An output signal is obtained, which is proportional to
the feedback value in the interval Minimum feedback,
FB
MIN
- Maximum feedback, FB
MAX
(parameter
414/415).
0-f
MAX
0-20 mA/4-20 mA.
An output signal is obtained, which is proportional to
the output frequency in the interval 0 - f
MAX
(parameter
202 Output frequency, high limit, f
MAX
).
0 - I
INV
0-20 mA/4-20 mA.
An output signal is obtained, which is proportional to
the output current in the interval 0 - I
INV
0 - P
M,N
0-20 mA/4-20 mA.
An output signal is obtained, which is proportional to
the present output power. 20 mA corresponds to the
value set in parameter 102 Motor power, P
M,N
.
0 - Temp.
MAX
0-20 mA/4-20 mA.
An output signal is obtained, which is proportional to
the present heatsink temperature. 0/4 mA corre-
sponds to a heatsink temperature of less than 20 °C,
and 20 mA corresponds to 100 °C.
323 Relay output 1-3
(RELAY 1-3 FUNCT.)
Value:
No function (no operation) [0]
Unit ready (unit ready) [1]
Enable/no warning (enable/no warning) [2]
Running (RUNNING) [3]
Running in reference, no warning
(run on ref/no warn) [4]
Running, no warnings
(RUNNING/NO WARNING) [5]
Running in reference range, no warnings
(RUN IN RANGE/ NO WARN) [6]
Ready - mains voltage within range
(RDY NO OVER/UNDERVOL) [7]
Alarm or warning
(ALARM OR WARNING) [8]
Current higher than current limit, par. 221
(Current limit) [9]
Alarm (ALARM) [10]
Output frequency higher than f
LOW
par. 225
(above frequency low) [11]
Output frequency lower than f
HIGH
par. 226
(below frequency high) [12]
Output current higher than I
LOW
par. 223
(above current low) [13]
VLT
®
2800 Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
40 MG.27.A2.02 - VLT
®
is a registered Danfoss trademark
